Prestressed bellows ntau lawm kab
Prestressed yeeb nkab khoom
Modular prestressed bellows ntaus ntawv
PVCPEPP ib leeg-phab ntsa, ob-phab ntsa tshuab, prestressed bellows ntau lawm kab
Kev tsim cov PVCPEPP ib leeg-phab ntsa thiab ob-phab ntsa tshuab cov kab ntau lawm feem ntau tsim PVC, PP, PE ua raw cov ntaub ntawv rau qhov loj ntawm caliber ib leeg thiab ob phab ntsa bellows.Smooth sab hauv thiab tawm, uniformly corrugated cov khoom yog molded los ntawm cov pwm coj ib zaug.
Cov kab ntau lawm yog nruab nrog ib tus ntsia hlau extruder extrusion PP thiab PE los yog ob lub ntsia hlau extruder extruding PVC, lub tshuab ua tshuab, lub raj log pwm, lub tshuab cua txias, ib meter 'meter', thiab lub tshuab winding, uas tuaj yeem ua tau. tsis tu ncua extruded rau ntau yam specifications loj thiab me me txoj kab uas hla bellows.
Cov qauv tsim ntawm cov ntsia hlau tshwj xeeb thiab pwm yog qhov tsim nyog, kev hloov pwm yog qhov yooj yim thiab txhim khu kev qha, uas daws qhov teeb meem ntawm kev hnav yooj yim ntawm cov ntsia hlau chim thiab qhov nyuaj ntawm cov khoom tsim, cov kab ntau lawm yog ceev, kev ua haujlwm ruaj khov, thiab kev tswj tau yooj yim thiab yooj yim rau kev khiav lag luam.
Lub tshuab ua tshuab yog cov qauv kaw, lub molding module txav rov qab mus rau hauv ib qho kev sib koom ua ke kaw qhov, lub qhov moulding yog tsim los rau cov qhaub cij, thiab lub tshuab ua kom txias txias yog uniformly txias los ntawm dej txias, thiab molding module tsis muaj. kev sib txuas nrog ib leeg, ua kom lub sijhawm luv luv los hloov cov kev qhia tshwj xeeb, kev ua haujlwm siab, thiab cua txias ceev.
Kev kub ceev tapered ntxaib ntsia hlau extruder party khoom siv yeeb nkab ua tshuab, siv Huichuan inverter thiab servo lub cev muaj zog, lub zog txuag 30% bearing siv thawj imports, siab kis tau tus mob lub neej, muaj peev xwm tiv taus lub siab tshaj plaws extrusion siab, ntsia hlau siv roj txias system, chim siv Taiwan kiv cua. cua txias, lub kaw lus siv lub computer tswj, raws li cov neeg siv khoom sib txawv, kev teeb tsa ntawm cov qauv tsim nyog tshaj plaws ntawm cov ntsia hlau, kom ua tiav lub xeev plasticization zoo tshaj plaws thiab kev xa khoom zoo, cov zis ntau dua, cov twj tso kua mis built-in, cov khoom siv hluav taws xob rau cov khoom siv. Qhov loj tshaj plaws siv cov khoom siv txawv teb chaws, thiab Nws muaj ntau lub tswb ua haujlwm tsis raug
Lub tshuab nqus tsev lub tshuab siv cov cuab yeej siv siab heev, kev tshawb nrhiav kev ywj pheej thiab kev tsim qauv tsim, tsim qauv tsim, kev ua tau zoo, ruaj khov, txhua feem yog nrog ntau tshaj kaum xyoo ntawm kev paub hauv tus tswv ua tib zoo tsim, cov qauv kev sib xyaw molding, pwm tom qab kev kho tshwj xeeb, muaj zog txias corrugated molding system, tuaj yeem ua kom muaj kev kub ceev ntawm kev tsim khoom tas mus li, cov txheej txheem lubrication siab ua kom cov molding module hnav qhov qis tshaj plaws, txhim khu lub neej kev pab cuam thiab precision ntawm pwm los tswj, online flaring muaj nuj nqi
Ntsia hlau, chim tsim thiab raug nqus European advanced technology
﹡Screw thiab chim khoom: 38CrMoAlA, nitriding kho
﹡ txais thawj cov khoom siv hluav taws xob nto moo nrog kev ua haujlwm ruaj khov.Piv txwv li:
RKC los yog Omron kub tswj, AC ceev regulator, low-voltage breaker txais Schneider los yog Siemens
﹡Gearbox txais siab torque, tsis tshua muaj suab nrov, nyuaj iav hniav lub ntsej muag iav lub thawv
﹡ Kev tiv thaiv tus kheej:
tam sim no ntawm lub cev muaj zog overload tsis siv neeg nres tiv thaiv
ntsia hlau hloov chaw tsis siv neeg nres tiv thaiv
Lubrication roj starvation tsis siv neeg tswb ntaus ntawv
| ﹡Screw, chim tsim thiab raug nqus European advanced technology ﹡Screw thiab chim khoom: 38CrMoAlA, nitriding kho ﹡ txais thawj cov khoom siv hluav taws xob nto moo nrog kev ua haujlwm ruaj khov.Piv txwv li: RKC los yog Omron kub tswj, AC ceev regulator, low-voltage breaker txais Schneider los yog Siemens ﹡Gearbox txais siab torque, tsis tshua muaj suab nrov, nyuaj iav hniav lub ntsej muag iav lub thawv ﹡ Kev tiv thaiv tus kheej: tam sim no ntawm lub cev muaj zog overload tsis siv neeg nres tiv thaiv ntsia hlau hloov chaw tsis siv neeg nres tiv thaiv Lubrication roj starvation tsis siv neeg tswb ntaus ntawv Screw thiab chim | |||
| 1 | Ntsia Hlau Diameter | mm | ￠ 65/132 |
| 2 | Ntsia hlau ntev | mm | 1430 ib |
| 3 | Khoom siv ntawm Screw thiab chim | / | 38CrMoAlA Nitrogen kho |
| 4 | Qhov tob ntawm nitration case | mm | 0.4-0.7 hli |
| 5 | Hardness ntawm nitration | HV | 940 hwv |
| 6 | Roughness ntawm qhov chaw | Ra | 0.4 ua |
| 7 | Hardness ntawm ob lub alloys | HRC | 55-62 : kuv |
| 8 | Qhov tob ntawm ob lub alloys | mm | 》2 |
| 9 | Lub zog cua sov | KW | 24 |
| 10 | Lub tshuab cua sov | / | Casting Aluminium rhaub |
| 11 | Barrel Cooling | / | Tsawg suab nrov blower txias |
| kis tau tus mob | |||
| 1 | Cov qauv siv tau | / | JB/T9050.1-1999 |
| 2 | Khoom siv ntawm iav thiab ncej | / | Txais yuav siab zog alloy, carburizing thiab quenching, sib tsoo |
| 3 | Gear precision thiab hardness | / | 6 qib, HRC 54-62 |
| 4 | Roj foob | Tag nrho cov sealing txais yuav cov khoom zoo | |
| 5 | Ntsia Hlau Tiv Thaiv | / | Tsis siv neeg ntsia hlau xaim tswb |
| Dosing feeding device | |||
| 1 | Hom | / | Ntsia hlau dosing feeder |
| 2 | Pub lub cev muaj zog | KW | 1.5 |
| 3 | Pub ceev regulator | / | Holi Hom Inverter |
| Lub cev muaj zog thiab hluav taws xob system | |||
| 1 | Lub cev muaj zog | KW | 37 (AC lub cev muaj zog) |
| 2 | Kev hloov ceev hom | / | Hollip los yog lwm yam kev hloov pauv hloov pauv nto moo |
| 3 | Max tso zis muaj peev xwm | Kg / h | 50-300 kg |
| 4 | Lub tshuab nqus tsev vacuum | / | los ntawm lub tshuab nqus tsev twj |
| 5 | Temperature Controller | / | RKC, Nyiv |
| 6 | AC contactor | / | Siemens |
| 7 | Qhov hluav taws xob | / | Raws li kev xav tau |
| 8 | Extruder axis qhov siab | mm | 1000 |
Corrugated modules ua los ntawm cov khoom siv tshwj xeeb alloy muaj qhov hardness siab heev thiab hnav tsis kam, thiab muaj cov cua sov zoo.
Qhov kev hloov pauv hloov pauv hloov siab heev tuaj yeem txo lub sijhawm los hloov lub module, thiab molding module nrog txawv waveforms tuaj yeem tsim raws li qhov sib txawv ntawm cov neeg siv khoom.
Post lub sij hawm: Lub Xya hli ntuj-22-2022
